• DIRAC LIVE Room Correction: Considered by industry leaders in music and movie production to be the state-of-the-art digital room correction solution, Dirac Live offers professional-grade, studio-quality calibrated sound with simple, easy-to-navigate tools. The result is a home theater experience that reveals your movies, music, and games in ways you’ve never heard before. Unlock the full potential of your loudspeakers in any listening space with Dirac Live.

• imax-enhanced: Hear the sound filmmakers intended.  This IMAX Enhanced A/V receiver features DTS:X sound technology optimized for the IMAX® signature experience, reproducing the full dynamic range of IMAX theatrical sound-mixes available with digitally re-mastered IMAX Enhanced content. A pre-set IMAX Mode reproduces audio at the highest levels and delivers an unmatched IMAX sound experience. Requires a free firmware update.

• Dolby Atmos Height Virtualizer: When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without the need for additional surround or height speakers.

• Dolby Atmos: Supports Dolby Atmos and DTS:X for an immersive three-dimensional sound-space through 7.2.2 or 5.2.4 channels. Individual sounds aren’t tied to channels and move naturally around your audience.

• Perfect for Custom Installation: Integra products are designed and engineered to meet the demands of leading custom installers. CI Centric features such as Web Setup, Onboard HDMI Diagnostics, and compatibility with Remote Monitoring systems like OVRC Pro and Domotz make Integra AVRs the choice of the modern integrator.  Optional rack mount kits provide a clean, finished look when installed in racks and cabinets, while a unique bright white back panel facilitates connections in hard-to-reach areas.

Other Features:

• Channels: 9

• Power Output: Watts per Channel: 100 W per channel (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)

• Dolby Atmos Height Virtualization

• DTS Virtual: X

• AccuReflex phase-matching solution for Dolby Atmos enabled speakers

• 3 programmable 12 V trigger-outs with adjustable delay (A: 100 mA, B: 25 mA, C: 25 mA)

• Works with Crestron®, Control4®, Savant, URC, ELAN, and RTI automation

• FM/AM Tuner 40 Presets

• Power Supply: AC 120 V~, 60 Hz

• Power Consumption: 750 W

• Standby Power Consumption: 0.1 W

• Works with Sonos supporting multiple Sonos Connect/Port control and Volume Passthrough mode

• Works with Alexa supporting multi-room music

• Works with Hey Google*14 and Chromecast built-in™

• AirPlay 2 multi-room audio with Siri voice control

• 3-Mode display dimmer (Normal/Dim/Dimmer)

• Weight: 11 kg

• Dimension (WxDxH): 43.5x37.65x17.4 cm
